Hospital Security Surveillance Layout
This comprehensive CCTV installation plan for Hermina Hospital Karawang spans four floors, featuring strategically positioned surveillance cameras throughout the facility. The drawing set (EC-201 through EC-204) details camera placement for optimal coverage of critical areas including entrances, corridors, nurses’ stations, waiting areas, and specialized medical departments.
Camera Specifications:
– Interior areas: Fixed dome cameras with varifocal lenses
– Exterior lobbies: Weather-resistant fixed cameras with housings, heaters, and blowers
– Camera coverage angles: 60° per indicated zones
Installation Details:
– Electronic shaft dimensions: 400 x 100 mm for cable ladder pathways
– Electrical shaft: 1000 x 400 mm
– Plumbing shaft: 1300 x 400 mm
– Exhaust fan shaft: 500 x 400 mm
Each floor plan identifies specific departments requiring surveillance coverage, with particular attention to high-security zones like ICU/PICU (6 beds), NICU (5 beds), Hemodialysis (7 beds), and isolation rooms. The design incorporates security monitoring for VIP wings, pharmacy areas, medical records, and payment/registration zones.
The surveillance system integrates with the hospital’s overall MEP infrastructure, with clearly marked pathways for cabling and connection to control systems. This security deployment balances patient privacy needs with protection of valuable medical equipment and controlled substances.
