CAD drawing of plumbing and drainage systems for an administrative office facility. The file provides separate floor plans for cold and hot water distribution and the sanitary drainage network. Layouts include specific rooms such as a laboratory, control room, multipurpose area, warehouse, and security station.
Detailed technical callouts show an electric water heater installation, masonry valve box construction, and register box sections with concrete specifications. The drawing includes a comprehensive legend for PVC and CPVC piping, ball valves, check valves, and flow meters. Technical specifications cover installation requirements for pressure-sealed PVC joints and bronze plumbing fixtures. Planta oficinas administrativas: redes de agua y desague.
