Site implementation and ground floor layout for a massive residential development featuring 22 blocks and 440 units in total. Includes a full site plan at 1/250 scale, internal road systems, and 163 parking spaces. Leisure zones are mapped out with a pet place, multiplay area, and communal edícula. Technical infrastructure is detailed, covering the water tower, ETE, and gas storage. You also get sections A-A and B-B, a front facade view, and elevation heights from +3.70 to +18.35. Complete area schedule and ventilation prism calcs included. Everything from bicycle racks to security gatehouse is here. Implantação e térreo para condomínio residencial com 22 bloocs e 440 unidades. Inclui planta de situação, cortes, fachada e quadro de áreas.
Residential Condominium Site Layout with 22 Blocks and Sections
