Air cooled packaged water chiller connection piping details

Isometric CAD drawing showing air-cooled chiller piping connections with valves, gauges, and flow switch labels.

Air cooled packaged water chiller hookup showing the full piping assemly. It’s an isometric view with callouts for the flow switch, balancing valves, pressure gauges, & flexible connections

FREE

File Details

File Type
DWG
Type
Detail
Language
English
Materials
Steel, Other
Units
Metric
Features
A/C
Uploaded by
DWG Master
Category
Engineering & Technical, Mechanical, Electrical & Plumbing (MEP)
Published
Jun 19, 2026

Download faster, ad-free, with more daily files from $7/mo

Tags

Cad Block chilled water piping chiller hookup commercial HVAC cooling system Engineering Drawing Flow Switch hvac detail isometric chiller mechanical detail mechanical equipment MEP drawing plumbing layout valves and gauges water chiller
