Section detail for an aluminum extrusion profile from Artminyum. It’s profile no. GNÇ 2513-23 (also ref 3962). Material is 6063-T66 alloy with a weight of 0.805 kg/m. Total width is 110mm and height is 50mm, incl. a 2mm wall thickness throughout. Follows EN 755-9 tolerance standards. Drawing shows 1:1 scale cross-section with dimensions for the 12.6mm center channel and 0.3mm radii.
Artminyum Aluminum Profile GNÇ 2513-23 Section Detail with Technical Specs
