A comprehensive fire safety plan for a hotel (B-1 occupancy) with emergency routes and equipment placement. The drawing details the installation of fire safety systems including:
Emergency Equipment:
– ABC 6.0kg fire extinguishers (4-A:40-B:C rated)
– Emergency lighting with battery backup
– Visual and audible fire alarms with manual activation points
– Central fire detection system
Building Classification Details:
– Building occupancy: Hotel (B-1) with 500 MJ/m² fire load
– Risk classification: Medium risk
– Fixed population: 5 people
– Required fire brigade: 5 members
Safety Signage:
– Escape route directional signs (10x20cm and 15x30cm)
– Exit identification signs at doorways
– Equipment location signage per NBR 13434-1/2 and IT 04/16 standards
The plan includes a central LPG installation with two 13kg cylinders following IT-28 requirements. All materials must meet Class I CMAR (fire resistance) standards for walls, floors, ceilings, and structural elements.
