Residential Floor Plan for Timóteo da Costa Multi-Family Building

Standard floor layout for a multi-family residential building in Leblon, Rio de Janeiro. The plan shows two spacious apartments per floor with dedicated social, service, and intimate areas. Each unit features:

Unit 1:
– Living/dining room (60.2m²) with open floor plan
– 4 bedrooms (10.8m², 9.7m², 11.3m², 10.8m²)
– 3 bathrooms (3.8m², 5.0m², 3.3m²) plus lavabo (1.6m²)
– Kitchen (11.3m²) with adjacent service area (5.4m²)
– Maid’s quarters (3.9m²) with bathroom
– Varanda (balcony) facing street

Unit 2:
– Combined living/dining space (48.9m²)
– 4 bedrooms including master suite (14.9m², 9.8m², 10.3m², 12.1m²)
– 2 bathrooms (3.8m², 3.8m²) plus lavabo (3.2m²)
– Kitchen (14.8m²) with service area (5.1m²)
– Maid’s quarters (4.0m²) with bathroom
– Central circulation hallway (7.9m²)

The building includes elevator access and follows typical Brazilian upper-middle class apartment layout conventions with clear separation between social, service and private zones.
