Sections AA and BB for a 15-story residential development incl. rooftop reservoir and machine room plans. Full vertical sections show elevator shafts, stairwells, and floor levels from the garage up to the penthouse units. Technical details for the dual 22,361 lts water tanks are provided at 1/75 scale, with floor-to-floor heights and machine room access noted.
Residential Building Sections and Water Reservoir Detail Drawings
