Retail Floor Plan for AEON Taman Maluri S06 Tenant Space
Second floor retail tenant plan (S06) for AEON Taman Maluri shopping mall extension. This plan details a 121.49 sqm (1307.71 sqft) tenant space with an additional 57.60 sqm (620 sqft) dedicated to internal outdoor seating. Layout includes clearly defined shopfront control lines and lease boundaries.
Key Features:
– Drainage systems with floor drains (FD1, FD2, FD3) and perimeter PC U-drain (300mm)
– Plumbing connections including waste pipes and stacks (various diameters from 80Ø to 150Ø)
– Multiple manholes (MH series) connecting to existing sewerage infrastructure
– AHU connections and mechanical services
– Fire protection elements with 2hr and 4hr fire-rated boundary walls
– North orientation with Kiblat direction indicated (292°32’0″)
The drawing includes concrete direct finish specifications for flooring and features detailed measurements in millimeters throughout. Connections to existing mechanical, electrical, and plumbing systems are thoroughly documented.
| Language | English |
| Drawing Type | Plan |
| Category | Retail |
| Additional Screenshots | |
| File Type | dwg |
| Materials | Concrete |
| Measurement Units | Metric |
| Footprint Area | 150 - 249 m² (1614.6 - 2680.2 ft²) |
| Building Features | A/C, Elevator, Escalator |
| Tags | drainage plan, fire rating, floor plan, lease line, MEP, retail tenant, shopping mall |
