Architectural details for baths, kitchens, closets, and doors (metal and wooden doors). Bathroom and kitchen details include plans, and internal elevation (sections) in scale 1:20. Doors and cabinets details include plans and elevations.Doors details are in scale 1:50, whereas the cabinets details are
| Language | English |
| Drawing Type | Plan |
| Category | Architectural |
| Additional Screenshots |
|
| File Type | dwg |
| Materials | Aluminum |
| Measurement Units | Metric |
| Footprint Area | 1 - 9 m² (10.8 - 96.9 ft²) |
| Building Features | Elevator |
| Tags | architectural, Blocks & Models, Cabinetry, Doors & Windows, Furniture & Appliances, Woodworking |
