Cultural Center Auditorium

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

stage, ss.hh., deposit, locker room, lobby, ticket office, shop-stand, pre-scene, projection room projection, scale :, plane :, responsible student :, alcantara hawthorn vladimir, auditorium, drawing cad :, lamina :, date :, trujillo – freedom, project :, cultural center, cycle, teachers :, location :, the ex-station, railway, arq. frame vizcarra jara, a.e.a.v., arq. rosa victoria albuquerque, vii, court a – a ‘, court b – b’, seats, emergency doors

Raw text data extracted from CAD file:

7.20 2.40 2.12 1.82 0.68 2.56 0.44 1.09 2.62 1.50 1.96 1.13 2.49 1.85 2.30 1.50 ESCENARIO SS.HH. SS.HH. DEPOSITO DEPOSITO VESTUARIO VESTÍBULO SS.HH. SS.HH. BOLETERÍA TIENDA-STAND NPT ± 0.00 m NPT - 0.72 m NPT ± 0.00 m NPT ± 0.00 m 01 02 03 04 01 02 03 04 VESTUARIO PRE-ESCENA PROYECCIÓN DE SALA DE PROYECCIONES NPT + 0.68 m NPT ± 0.00 m NPT ± 0.00 m 5 NPT ± 0.00 m NPT ± 0.00 m NPT ± 0.00 m A-05 ESCALA: PLANO: COD. 2032013552 EST. ARQ° ALUMNO RESPONSABLE: ALCÁNTARA ESPINO VLADIMIR AUDITORIO DIBUJO CAD: LAMINA: FECHA: TRUJILLO - LA LIBERTAD ENERO, 2007 PROYECTO: CENTRO CULTURAL CICLO DOCENTES: UBICACION: 1/100 LA EX-ESTACIÓN DEL FERROCARRIL ARQ. MARCO VIZCARRA JARA A.E.A.V. ARQ. ROSA VICTORIA ALBUQUERQUE VII U C V A A B B CORTE A - A' 5 5 5 NPT ± 0.00 NPT - 0.72 NPT - 0.72 NPT ± 0.00 m NPT + 0.68 m 5 5 5 5 5 NPT + 5.15 m 5 CORTE B - B' ESCENARIO BUTACAS BUTACAS PUERTAS DE EMERGENCIA PUERTAS DE EMERGENCIA PUERTAS DE EMERGENCIA 5 5 5 5 5 5
