Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

bylayer, global, armor of faith, bottom grill calculated, iron, Foundation, poor concrete, Esc., against concrete floor, ceramic floor, griddle, holding faith, ceramic floor, bond cement cement mixture, mortar of hº, Esc., galvanized pipe, railing, platinum, balcony stairs, of union grada railing, perspective, cut, trace of, against footprint

Raw text data extracted from CAD file:

. . BYLAYER -1.0000,-1.0000,-1.0000 1.0,1.0,1.0 ("nullsurf" "") (11 "Ka" "0.7")(11 "Kd" "1")(11 "Ks" "0.2")(11 "roughness" "0.5") -1.0 ("nulldisp" "") 0.0 0 ("" "") 0.0 0.0 1.0 0.0 0.0 1.0 1.0 1.0 GLOBAL -1.0000,-1.0000,-1.0000 1.0,1.0,1.0 ("nullsurf" "") (11 "Ka" "0.7")(11 "Kd" "1")(11 "Ks" "0.2")(11 "roughness" "0.5") -1.0 ("nulldisp" "") 0.0 0 ("" "") 0.0 0.0 1.0 0.0 0.0 1.0 1.0 1.0 Armadura de Fe d3/8" Parrilla inferior Fe calculado Fierro d5/16" Cimiento H° A° Hormigon pobre Esc. 1:25 Contra piso de hormigon Piso cerámico Plancha 1/4"esp. Sujeción Fe d1/2"x2" Piso cerámico Mezcla de unión c/ cemento cola Mortero de Hº Esc. 1:50 Tubo galvanizado d3/4" Baranda de 2"x2" Platino 1" GRADAS Y VARANDA DETALLE-A de Union grada baranda DETALLE-A PERSPECTIVA CORTE . . Huella de 30cm. Contra Huella de 18cm.
