Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Tank nozzle, With tank connection, Phase ii vapors, Recovery stretcher, Towards the tank, Dispensaries with slope, Of vapors comes from, Recovery pipe, Return of vapors, Pipe fittings mm., floating, ball valve, Model brand, Line of vent of mm., Variable height depending, Pend. Minimum to the tank, Return vent connection vent, detail, Of vapors cap, Rigid connection, Recovery adapter, Registration for

Raw text data extracted from CAD file:

BOQUILLA EN TANQUE CON CONEXION DE 4 " AL TANQUE DE VAPORES FASE II ESTRACTOR DE RECUPERACION DE 1 % HACIA EL TANQUE ) DISPENSARIOS CON PENDIENTE DE VAPORES ( VIENE DE TUBERIA DE RECUPERACION RETORNO DE VAPORES TUBO Y ACCESORIOS 101 MM. ( 4") FLOTANTE VALVULA DE BOLA DE MARCA Y MODELO LINEA DE VENTEO DE 76.2 MM. 3" ALTURA VARIABLE DEPENDIENDO PEND. 1 % MINIMO HACIA EL TANQUE CONEXION DE RETORNO DE VAPORES Y VENTEO DETALLE 5 DE VAPORES Y TAPA CONEXION RIGIDA ADAPTADOR PARA RECUPERACION REGISTRO PARA
