Constructive Detail Of Fixative For Curtain Wall DWG Detail for AutoCAD

Constructive Detail Of Fixative For Curtain Wall DWG Detail for AutoCAD

Constructive detail of metallic fixative for curtain wall

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

detail crampon, keyway, specification, material, glass fixation, isometric, screw security

Raw text data extracted from CAD file:

DETALLE GRAMPÓN CUERPO ( 1 ) EJE ROSCADO ø 18 mm. ( 2 ) ANILLO SOPORTE VIDRIO ( 4 ) ARANDELA ROSCADA PARA BLOQUEO ( 3 ) SOPORTE GRANPON ø 16.5 ( 8 ) TUERCA AUTOFRENADA DIN 985 ( 7 ) ARANDELA AISLANTE ( 5 ) TUERCA H DIN 934 ( 6 ) ARANDELA AMORTIGUADORA ( 9 ) ARANDELA AMORTIGUADORA ( 9 ) CHAVETERO 1 ACERO INOXIDABLE AISI 316 L ESPECIFICACIÓN 2 ACERO INOXIDABLE AISI 316 L 3 ACERO INOXIDABLE AISI 316 L 4 ALUMINIO EN AW 1050 - ANODIZADO 5 POLIAMIDA / POLIACETAL 6 ACERO INOXIDABLE A4 7 ACERO INOXIDABLE A4 8 ACERO INOXIDABLE AISI 304 9 ACERO INOXIDABLE AISI 315 NEOPRENO ( 65 Sh ) MATERIAL FIJACIÓN VIDRIO ISOMETRICA S / E TORNILLO SEGURIDAD

Language	Spanish
Drawing Type	Detail
Category	Doors & Windows
Additional Screenshots
File Type	dwg
Materials	Glass, Other
Measurement Units	Metric
Footprint Area
Building Features
Tags	autocad, constructive, curtain, DETAIL, DWG, metallic, wall
