Constructive Joint Between Slabs DWG Block for AutoCAD

Constructive Joint Between Slabs DWG Block for AutoCAD

Seismic structure – constructive joint between slabs

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Abrasive cleaning, To waterproof with similar sika, Reinforcement, Sikaflex putty, Sikarod, depth, width, Concrete structure, Form factor sikaflex mm, Nice metal, Detail of joint between slabs, N.a., Wall, Thick floor, Mezzanine floor

Raw text data extracted from CAD file:

\A1;0.02 m \A1;0.15 m \A1;0.15 m LIMPIEZA CON DISCO ABRASIVO IMPERMEABILIZAR CON SIKA O SIMILAR REFUERZO QUE ATRAVIESA MASILLA SIKAFLEX 1A SIKAROD Ø 1 1/8" (29 mm.) PROFUNDIDAD = 1 ANCHO = 2 ESTRUCTURA EN CONCRETO FACTOR DE FORMA SIKAFLEX 1A=ANCHO=20 mm O GRATA METALICA \A1; DETALLE DE JUNTA CONSTRUCTIVA ENTRE LOSAS N.P.A MURO MURO 5 5 5 ESPESOR PISO ENTREPISO Y/O CEBADÒ

Language	Spanish
Drawing Type	Block
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features
Tags	autocad, block, constructive, DWG, erdbebensicher strukturen, joint, seismic, seismic structures, slabs, structure, strukturen
