Control Valve – 5/3 Valve Pneumatic Symbols

Control Valve – 5/3 Valve Pneumatic Symbols

– All ports sealed, basic
– All ports sealed, normal
– All ports sealed, 1st position
– All ports sealed, 2nd position
– Supply port only sealed, basic
– Supply port only sealed, normal
Autocad 2004 version

Language	English
Drawing Type	Block
Category	Industrial
Additional Screenshots
File Type	dwg, Image file
Materials	Other
Measurement Units	Imperial
Footprint Area
Building Features
Tags	– All ports sealed, 1st position – All ports sealed, 2nd position – Supply port only sealed, basic – All ports sealed, basic – Supply port only sealed, normal, normal – All ports sealed
