Detail insulating coating plate and ashlar applied on wall block

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

class, dimensions, thickness: cm, design weight, width: cm, on plate, longitude: cm, in cm plate, Thermal conductivity, thermal insulation sheet, each row, connector sheets, adhesive mortar hebel, laminating fixation, concrete support, side view of the wall, detail of hebel insulation panel on wall, concrete support, reinforced concrete support, concrete nail, galvanized nail, wall cut, front view, data sheet, padded gasket detail, view of the wall, interior detail of double wall with niche, cm mortar joint with sand cement proportion, light block, niche, ashlar plate, adhesive mortar, side view of the wall, concrete support, wall cut, front view, mesh reinforcement, wire staples, adhesive mortar, ashlar plate, ashlar plate

Raw text data extracted from CAD file:

\A1;1.25 \A1;5 cm \A1;10 cm \A1;7 cm CLASE DIMENSIONES AAC-2 ESPESOR: 5-7.5 Cm Peso de diseño ANCHO: 20.00 cm 28 kg/m2 en placa de 5cm Longuitud: 62.5 cm 40 kg/m2 en placa de 7.5 cm Conductividad Termica Pza./m2 8.00 0.0946 W/mk \A1;.045 \A1;0.25 \A1;.025 1.25 Placa Termoaislante A cada 2 hiladas Laminas Conectoras Mortero Adhesivo Hebel Fijacion de Laminilla 5 10 cm Apoyo de concreto 7 cm Vista Lateral del muro Detalle de Placa Termoaislante Hebel Sobre muro Apoyo de Concreto Apoyo de Concreto reforzado Clavo para Concreto Clavo Galvanizado 2-1/2 CORTE DE MURO VISTA FRONTAL FICHA TECNICA Detalle de la Junta Almohadillado Vista del muro Detalle interior del doble muro con nicho Junta de mortero de 1 cm con cemento arena proporcion 1:3 Block ligero de .15x.20x.40 Nicho Placa de Sillar Mortero Adhesivo Vista Lateral del muro Apoyo de Concreto CORTE DE MURO VISTA FRONTAL Refuerzo de malla electrosldada 6x6 Refuerzo de malla electrosldada 6x6 Grapas de alambron Mortero Adhesivo Placa de Sillar .045 0.25 .025 Placa de Sillar
