Detail Ribbed Slab DWG Detail for AutoCAD

Detail Ribbed Slab DWG Detail for AutoCAD

Detail plane and isometric ribbed slab taking into account all the required specifications

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

raised, compression slab, stage, polin, godmother beam, isometric, ribbed slab, mts, isometric, slab ribbed with polystyrene blocks., mts, isometric, raised, compression slab, stage, polin, godmother beam, polystyrene blocks., the seal

Raw text data extracted from CAD file:

0,50 0,05 0,20 1.50 0,50 1.50 0,05 0,20 0.40 0.40 ALZADO 2ø4 5 6-6 10/10 Losa De Compresion 5 5 Tarima 0.50x1.00x0.10 Polin 4´´x4´´x4´´ Viga Madrina 1.50 ø3 ISOMETRICO LOSA NERVADA 5.00x5.00 MTS ISOMETRICO LOSA NERVADA CON BLOQUES DE POLIESTIRENO. 5.00x5.00 MTS ISOMETRICO 0.40 0.40 ALZADO 2ø4 5 6-6 10/10 Losa De Compresion 5 5 Tarima 0.50x1.00x0.10 Polin 4´´x4´´x4´´ Viga Madrina 1.50 ø3 BLOQUES DE POLIESTIRENO. LOSACERO

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Other
Measurement Units
Footprint Area
Building Features
Tags	account, alveoplaca, autocad, DETAIL, DWG, isometric, leichte struktur, lightweight structure, plane, required, ribbed, ribbed slab, slab, specifications
