Details Cimentacion DWG Detail for AutoCAD

Details include adjoining masonry foundation and intermediate cimentacion with all appropriate specifications.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

intermediate foundation, masonry made with stone slab bonded with mortar, curb chain made with reinforced concrete, template made with simple concrete, with a, adjacent foundation, recessed red clay wall wall, of cm bonded with mortar, with a proportion of cement can, wire rod, with attached rods with stirrups, of one dimension of cement can, cans of coarse sand., gross sand., uaslp, digital drawing, structural detail, scale

Raw text data extracted from CAD file:

\A1;0.08 \A1;0.80 \A1;0.17 \A1;0.62 \A1;0.08 \A1;0.80 \A1;0.17 \A1;0.62 Cimentación Intermedia Mamposteria hecha con piedra laja unida con mortero Cadena de desplante hecha con concreto armado 0.08 0.80 0.17 0.62 Plantilla hecha con Concreto Simple con una dimensión100 kg/cm Cimentación Colindante Muro de tabique de barro rojo recosido de 15 x 5 cm unido con mortero con una proporcion de 1 lata de cemento alambrón de 1/4'' 0.08 0.80 0.17 0.62 con 4 varillas de 1/2'' unida con estribos de de una dimension de 1 lata de cemento y 5 latas de 1 B y 5 latas de arena gruesa. arena gruesa. 2 UASLP DIBUJO DIGITAL DETALLE ESTRUCTURAL Escala 1:20
