Detail of a warehouse housing components

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

of long. max., of forged castelo, beam spout type, expanded against party, of f. castle, coronation auction, made of galvanized sheet, polystyrene plate, of forged castelo, prefabricated pillar, head channel, enclosure with hollow slab in horizontal, beam type tauver of f. castle, h belt armed, extruded sandwich type, with polystyrene soul, double lacquered metal sheet

Raw text data extracted from CAD file:

de e=15cm, h=1,20m y long. max. 8m de Forjados Castelo Viga Canalón Tipo "H-40" Expandido contra medianera de F. Castelo Remate de coronación de chapa galvanizada Plancha de Poliestireno de Forjados Castelo Pilar Prefabricado de cabezal canal 40x40 Cerramiento con losa hueca en horizontal Viga Tipo Tauver de F. Castelo Correa de H. Armado extruído tipo sandwich con alma de poliestireno Doble chapa metálica lacada de 25x12cm

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
