Details DWG Detail for AutoCAD
Details landscape
Drawing labels, details, and other text information extracted from the CAD file:
pvc pipe to storm drain to detail, concrete curb, rolled cast concrete curb, concrete crub, mm cast iron grille drain cover, rolled cast concrete curb drain inlet, concrete curb, mm cast iron grille drain cover, mm batu candi header set on mortar bed, perforated pipe to storm drain, geotextile fabric, mm decorative pebble, mm concrete pad, cast bronze drain inlet bronze screen, plan view, cast bronze drain inlet bronze screen, mm concrete pad, pvc pipe to drain, section, pipe to drain, mm decorative pebble, mm perforated concrete drain cover, to drain, concrete to eng. detail, concrete to eng. detail, mm perforated concrete drain cover, plan view, section, varies, jogging track reinforced concrete slab pebble wash finish color texture to be approved by l.a., pool deck reinforced concrete slab pebble wash finish color texture to be approved by l.a.
Raw text data extracted from CAD file:
| Language | English |
| Drawing Type | Detail |
| Category | Construction Details & Systems |
| Additional Screenshots |
 |
| File Type | dwg |
| Materials | Concrete |
| Measurement Units | |
| Footprint Area | |
| Building Features | Pool, Deck / Patio |
| Tags | autocad, construction details section, cut construction details, DETAIL, details, DWG, landscape |
