Emergency Gate DWG Block for AutoCAD

Emergency Gate DWG Block for AutoCAD

Emergency gate 2 Leaves – inferior slid

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

plane number:, gate guide, detail, poor concrete folder, wheel guide, concrete, internal side of the property, detail: path porton, see note, cap, l.c. wheel, gate post, wiring with frame with screw for iron plate guides., stretch., to the frame., see detail, nut, thread and, according to dimensions and type of installation, pos., req. , description, list of materials

Raw text data extracted from CAD file:

\A1;0.60 \A1;0.10 \A1;0.10 \A1;30° \A1;3.50 \A1;0.40 x 0.40 \A1;2.40 NUMERO DE PLANO: 1 2 3 4 5 6 J I H G F E D C B A FORMATO IRAM A2 ( 594mm x 420mm ) \A1;100 -156.8066995737931 7 3 GUIA PORTON DETALLE CARPETA HORMIGON POBRE 5 GUIA DE RUEDA -156.8066995737931 -156.8066995737931 -156.8066995737931 -156.8066995737931 -156.8066995737931 CONCRETO LADO INTERNO DEL PREDIO DETALLE: RECORRIDO PORTON VER NOTA GUIA DE RUEDA TOPE 120° R: 1100 L.C. RUEDA = 100 POSTE DE PORTON HERRAJES:3 BISAGRAS POR HOJA REFORZADAS DE 100mm SOLDADAS d16. RUEDAS DE APOYO SOBRE GUIAS CON SUSPENSION ELASTICA. ARO d120 mm EN PLANCHUELA DE HIERRO =30x6 mm, TENSORES ALAMBRADO CON BASTIDOR DE PLANCHUELA CON TORNILLO PARA PLANCHUELA DE 200x100x10 CON TOPE SOLDADO TEJIDO DE ALAMBRE IDEM 80x100x8 mm SOLDADA AL PORTON.EN EL PISO BLOQUE DE H° CON 70x70 mm.PASADORES DE ACERO d15 LARGO 400mm TOPE DE CHAPA CIERRE: PORTACANDADO Y CANDADO TIPO "YALE" DE BRONCE MACIZO GUIAS DE PLANCHUELAS DE HIERRO. ESTIRAR. AL BASTIDOR. PORTON:2 HOJAS,BASTIDOR CANO DE ACERO SIN COSTURA 38mm. 0.40 0.25 4 VER DETALLE 0.30 =1.10 0.025 1 0.0 5 TUERCA 2 ROSCA Y 6 DIAGONALES CANO Ac. CARBONO d25 mm. SOLD. AL ANILLO POS. 14 ARO DE 120 mm EN PLANCHUELA HIERRO 30 x 4.8 mm ALAMBRADO: TEJIDO DE ALAMBRE DE HIERRO GALVANIZADO BWG N°10 (3-4 mm) MALLA ROMBOIDAL DE 51 mm DE 2000 mm DE ALTURA. ALAMBRE DE PUA GALVANIZADO DE 4" RESISTENCIA 17/15 SEGUN DIMENSIONES Y TIPO DE LA INSTALACION 7 * * 6 5 4 * * * POS. 1 2 3 * * REQ. * POSTE DE TRANQUERA DE H°A° DE 150 x 150 mm ESPIRAL d4.2 mm c/100 mm CANO DE ACERO d38 mm MINIMO ~ BISAGRAS DE 100 mm DESCRIPCION LISTA DE MATERIALES

Language	Spanish
Drawing Type	Block
Category	Doors & Windows
Additional Screenshots
File Type	dwg
Materials	Concrete, Other
Measurement Units	Metric
Footprint Area
Building Features
Tags	autocad, block, DWG, emergency, gate, leaves
