Entresol DWG Detail for AutoCAD

Entresol DWG Detail for AutoCAD

Detail entresol with alveolar plate and metallic beam

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

False floor concrete slab cm connector steel pontoon cofrastra stone added aluminum sheet insulation cement bonded on stainless steel structure. Beam heb joint with hollow aluminum alveolar beam cm false ceiling, Coupe type sur rive, Echelle

Raw text data extracted from CAD file:

\A1;70 \A1;36 \A1;14 \A1;70 \A1;30 5 36 14 5 5 1. Suelo Falso 2. Losa de Hormigon 14 cm 3. Conector 4. Pontón de Acero Cofrastra 5. Piedra agregada 6. Chapa de aluminio 7. Aislante 8. Cemento unida sobre estructura metalica inoxidable. 9. Viga HEB 240 10. Junta con hueco en aluminio 11. Viga alveolar 36 cm 12. Plafon falso 7 cm 1 2 3 4 11 12 10 5 6 7 8 9 COUPE TYPE SUR RIVE ECHELLE : 1/10°

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Aluminum, Concrete, Steel
Measurement Units
Footprint Area
Building Features
Tags	alveolar, autocad, beam, DETAIL, DWG, entresol, metallic, plate, stahlrahmen, stahlträger, steel, steel beam, steel frame, structure en acier
