Armed with insulated flooring components to air and impact noise

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

air impact noise insulation, floor, legend:, support., insulation panel., rocdan, rubber cushions., impact noise insulation., mortar. reinforced with mesh., thickness with each, finishing pavement., impact, rocdan, Applications, cinemas, dishes, disco bar, recording rooms, percussion cabinets, machine rooms, impact, aerobig

Raw text data extracted from CAD file:

AISLAMIENTO A RUIDO AEREO Y DE IMPACTO SUELO LEYENDA: 1. SOPORTE. 2. PANEL DE AISLAMIENTO. (Densidad 100 kg/m2). ROCDAN 233/30 3. AMORTIGUADORES DE CAUCHO. d100 4. AISLAMIENTO A RUIDO DE IMPACTO. 5. MORTERO. Armado con mallazo. Espesor 7 con d6 cada 20. 1 3 5 2 4 6 6. PAVIMENTO DE TERMINACION. IMPACTODAN ROCDAN APLICACIONES 3 TEATROS, CINES AUDITORIOS, PLATOS T.V., KARAOKE, DISCOTECA, DISCO BAR SALAS DE GRABACION CABINAS PERCUSION SALAS DE MAQUINAS 5 10 IMPACTODAN GIMNASIOS, AEROBIG BA-400 + BA-400
