Hotel is set in the center of the city of Piura, the land is in a corner, and unification is achieved in the drive around the city. takes into account the guidance ..

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

ppm – wooden doors:, wood carpentry, some models are also manufactured in gray concrete, units in millimeters, model kl, file – balustrades all models, are manufactured in white concrete, model kj, model lx, model jr, model xt , model mt, model plt, model mt-corrido, model kit, model at, treadmill, double bedroom, single bedroom, wall, made by coconut, frontal elevation, lateral elevation., patio, mezzanine, living-dining room, unoccupied, kitchen , court aa, street liberty, jiron apurimac, closet, parking, maneuvering area, auditorium, laundry, lobby, entrance, sum, commercial gallery, topico
