Jib cranes for landing

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Rotating pen with manual operation, Code designation dimension material, Number., fine, half, gross, tolerance, general, Bevelled edges, modified, title:, detail, draft:, Senati, scale, Replaced by:, Replaced by:, date, first name, area, Mmh, Drawn, reviewed, Approved, Plan no, Concrete reinforced concrete

Raw text data extracted from CAD file:

8"Nom 175 150 25Groutng 175 175 PL3/4" 350 500 350 500 PLUMA GIRATORIA CON ACCIONAMIENTO MANUAL 0,8 Pza\H1.301x; \H0.7684x;Cant Codigo Denominacion Dimension Material Cantida. Fina Media Gruesa >0,5 >3 >0.6 >30 >120 >140 >1000 >2000 ..1000 ...400 ...120 ...30 ...6 ...3 0,1 0,1 0,2 0,3 0,5 1,2 Tolerancia general Aristas Biseladas 0.5x45" Modificado a b c d e TITULO: DETALLE " A " PROYECTO: SENATI Escala Remplazado por: Remplazado de: 1:10 fecha Nombre Area MM.HH Dibujado Revisado Aprovado Plano Nº - A4/15 Z6 16 8"Nom 175 150 25Groutng 175 175 PL3/4" 18 17 \LCORTE A - A 350 500 350 500 Terreno y concreto armado A A NIV.0.00

Language	Spanish
Drawing Type	Block
