Details of Keystone block

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Height, On the fixing pins., Of the filling is completed, The geotextile is placed level, top, Standard unit, top, Standard plant, Standard lift, Standard unit, Connection of geotextile fastening pins, Progression of lids on the wall, section, Base template detail, elevation, Simple reinforced concrete base template, The dimensions weights can vary by region, depth:, width:, weight:, height:, Standard unit, Lbs, top, weight:, height:, depth:, width:, Lbs, Dimensions may vary by section, Step, Slope cut, Block face, Base template, Simple concrete, Direction of force, Base template, Of simple concrete, Standard unit near vertical setback, Reinforced floor, Retained floor, Typical section of keystone wall, Standard keystone unit, Design height, Keystone cap, filter, Geotextile

Raw text data extracted from CAD file:

\A1;8" \A1;18" \A1;21 1/2" \A1;7 1/4" \A1;36" \A1;Design Height \A1;Geotextil sobre los pines de fijacion. del relleno y se exitende El Geotextil se coloca a nivel Tapa Unidad Estandar Tapa Planta estandar Elevacion Estandar Unidad Estandar Conexion de Geotextil y pines de fijacion Progresion de tapas en la pared 8" 18" Seccion Detalle de Plantilla Base 21 1/2" 7 1/4" 36" Elevacion Plantilla base de concreto simple sin refuerzo Las dimensiones y pesos pueden variar por region Profundidad: Ancho: Peso: Altura: Unidad Estandar 8" 115 lbs 21 1/2" 18" Tapa Peso: Altura: Profundidad: Ancho: 45 lbs 18" 10 1/2" 4" Dimensiones pueden variar por seccion 8" Step Slope Cut Cara de bloque Plantilla base de concreto simple Direccion de fuerza Plantilla base de concreto simple \A1;21 1/2" ± Standard Unit - Near Vertical Setback Suelo Reforzado Suelo Retenido Seccion Tipica de Muro Keystone Unidad Estandar de Keystone Design Height Tapa de Keystone 1 32 Filtro (3/4" ) 24" Geotextil

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features	Car Parking Lot
Tags	autocad, betonsteine, block, concrete block, DETAIL, details, DWG, walls
