Losacero Detail 3D DWG Detail for AutoCAD

Detail 3D armor connection – Losacero

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

losacero romsa, of diameter, welding point, losacero system., components of the, structure, welded Mesh, go placed cm., concrete., below the surface of the, composed, MMM., head bolt, to form section, cutting pins, concrete

Raw text data extracted from CAD file:

LOSACERO ROMSA. 20mm DE DAMETRO PUNTO DE SOLDADURA DE SISTEMA LOSACERO. COMPONENTES DEL ESTRUCTURA MALLA ELECTROSOLDADA (DEBERA IR COLOCADA 2 cm. CONCRETO. ABAJO DE LA SUPERFICIE DEL COMPUESTA L=51 mm x 13 mm. PERNO CON CABEZA PARA FORMAR SECCION PERNOS DE CORTANTE CONCRETO

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
