Mill Sac DWG Block for AutoCAD

Mill Sac DWG Block for AutoCAD

Mill and parts of minerolurgia area in one of the production areas of a mine

Drawing labels, details, and other text information extracted from the CAD file:

discharge cone, trunnion liner, discharge head, inching drive, pinion – bearing pedestal, inching coupling guard, pinion, pinion bearings, clutch, motor – bearing pedestal, feed chute, trunnion bearing, feed head, operating floor, ring gear, gear guard, shell lifters, grates

Raw text data extracted from CAD file:

DISCHARGE CONE DISCHARGE TRUNNION (BEARING NOT SHOWN) TRUNNION LINER DISCHARGE HEAD INCHING DRIVE PINION - BEARING PEDESTAL INCHING COUPLING GUARD PINION PINION BEARINGS CLUTCH MOTOR - BEARING PEDESTAL MOTOR (OTHER MOTOR BEHIND) FEED CHUTE TRUNNION BEARING FEED HEAD OPERATING FLOOR RING GEAR GEAR GUARD SHELL LIFTERS GRATES PULP LIFTERS (ACTUALLY CURVED - SHOWN STRAIGHT FOR CLARITY)
