A museum that has everything; as a sum; a reading room; library and bungalow are three levels

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

hall, central square, sick, reading room, internet room, guide room, ss.hh. ladies, reception, control, ticket office, audiovisual room, attention, bookcase, office, entrance, stairs, dep., guard., pool ornament., stands souvenirs, gazebo, ss.hh. males, dress. ladies, depos., cto. of maq., deposit, elect. group, cafeteria, sum, auditorium, kitchen, s.h., pantry, s.h. d, observatory, foyer, proy booth, spectators area, stage, workshop a, bar, sub. station, square, s.h. v, be common, lobby, store, cloakroom, staircase, limp., ramp, elect board, conference room, living room, meeting room, kitchenette, introductory room
