Opening fixation detail

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

false ceiling, aluminum channel to absorb unevenness, aluminum bushing, cancel, rawl plus type tappet, aluminum base, n.p.t., perspective, n.l.b. mezzanine, holes, variable, side elevation, front elevation

Raw text data extracted from CAD file:

LAMINA # 14 MADERA DE PINO DE 100X21MM CORRIDA FALSO PLAFON CANAL DE ALUMINIO PARA ABSORBER DESNIVELES MANGUETE DE ALUMINIO CANCEL BARRENO DE 13 mm BARRENO DE 45 mm TAQUETE TIPO RAWL PLUS ZOCLO DE ALUMINIO N.P.T. PERSPECTIVA DETALLE (2) DETALLE (3) 50 mm 50 mm TAQUETE TIPO RAWL PLUS LAMINA # 16 N.L.B. ENTREPISO DETALLE (1) 50 mm 100 mm 25 mm 25 mm 50 mm 100 mm 50 mm 50 mm 50 mm 100 mm 50 mm 25 mm 25 mm LAMINA # 16 BARRENOS PLANTA DETALLE (2) PLANTA DETALLE (1) 100 mm 30 mm 31 mm VARIABLE LAMINA # 16 MADERA 100X31 mm FALSO PLAFON CANAL DE ALUMINIO PARA ABSORBER DESNIVELES MANGUETE DE ALUMINIO CANCEL N.L.B. ENTREPISO ALZADO LATERAL 30 mm 31 mm VARIABLE LAMINA # 16 MADERA 100X31 mm FALSO PLAFON DETALLE 2 CANAL DE ALUMINIO PARA ABSORBER DESNIVELES MANGUETE DE ALUMINIO CANCEL 100 mm DETALLE 3 N.P.T. ALZADO FRONTAL DETALLE 1

Language	Spanish
Drawing Type	Detail
Category	Doors & Windows
Additional Screenshots
File Type	dwg
Materials	Aluminum, Other
Measurement Units	Metric
Footprint Area
Building Features
Tags	autocad, Construction detail, DETAIL, DWG, fixation, opening
