Anchorage panel wall – foundation

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

column, detail panel wall, proportion, mortar cement sand, polystyrene, structure panel, foundation panel wall, anchor detail, cut, foundation, proportion, mortar cement sand, polystyrene, v’s, structure panel

Raw text data extracted from CAD file:

\A1; COLUMNA 30 x 45cm DETALLE MURO DE PANEL PROPORCION 1:4 MORTERO CEMENTO ARENA POLIESTIRENO f'y= 5,000 Kg/cm2 ESTRUCTURA PANEL MURO DE PANEL A CIMENTACION DETALLE DE ANCLAJE 6 cm CORTE 20 CIMIENTO PROPORCION 1:4 MORTERO CEMENTO ARENA POLIESTIRENO 40 V's #3 @ 30cm f'y= 5,000 Kg/cm2 ESTRUCTURA PANEL
