Park This is a park at project level has an administration; nursery; Internet area; Closets; SS.HH; sum; two soccer fields and a slab of Natural gras; playgrounds; park and parking area .

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

pool, statue duck of lagoon, p. of arq enrique guerrero hernández., p. of arq Adriana. rosemary arguelles., p. of arq francisco espitia ramos., p. of arq hugo suárez ramírez., administration, nursery, internet, men’s clothing, women’s wardrobes, ss.hh, machines, sum, kiosk, court a-a, b-b court, snak, esquey track -concrete, playground, gym, amphitheater

Raw text data extracted from CAD file:

\A1;R.60 \A1;R1.00 \A1;R.20 -745.2726022833859 -745.2726022833859 PILETA Estatua Pato de laguna Estatua Pato de laguna -745.2726022833847 N.P.T+0.00 P. de Arq. Enrique Guerrero Hernández. P. de Arq. Adrian A. Romero Arguelles. P. de Arq. Francisco Espitia Ramos. P. de Arq. Hugo Suárez Ramírez. N N.P.T+0.15 N.P.T-.90 N.P.T+0.10 N.P.T+0.15 N.P.T+0.15 N.P.T+0.15 N.P.T+0.15 N.P.T+0.15 N.P.T+0.00 N.P.T+0.10 3 2 1 4 N.P.T+0.10 N.P.T+0.10 N.P.T+0.30 N.P.T+0.15 N.P.T+0.60 N.P.T+0.10 2 N.P.T+0.30 1 ADMINISTRACION GUARDERIA INTERNET VESTURIO HOMBRES VESTUARIOS MUJERES SS.HH SS.HH MAQUINAS P. de Arq. Enrique Guerrero Hernández. P. de Arq. Adrian A. Romero Arguelles. P. de Arq. Francisco Espitia Ramos. P. de Arq. Hugo Suárez Ramírez. A A B B N.P.T+0.15 N.P.T+0.15 N.P.T+0.10 SUM 1 2 3 4 5 6 QUIOSCO QUIOSCO N.P.T+0.10 N.P.T+0.10 N.P.T+4.00 CORTE A-A N.P.T+3.30 N.P.T+0.00 N.P.T+0.00 N.P.T+0.30 N.P.T+0.30 N.P.T+4.00 N.P.T+3.28 N.P.T+4.80 CORTE B-B N.P.T+0.00 N.P.T+0.00 SNAK PISTA DE ESQUEY -CONCRETO JUEGOS INFANTILES GIMNASIO ANFITEATRO N.P.T+0.60

Language	Spanish
Drawing Type	Full Project
Category	Parks & Landscaping
Additional Screenshots
File Type	dwg
Materials	Concrete, Other
Measurement Units	Metric
Footprint Area
Building Features	Garden / Park, Pool, Parking
Tags	administration, amphitheater, area, autocad, closets, DWG, full, internet, Level, nursery, park, parque, Project, recreation center, sshh
