Pilar – Start Union Articulated DWG Block for AutoCAD

Pilar – Start Union Articulated DWG Block for AutoCAD

Start HEB Union articulated Pilar – Pilar start Circular Union articulated –

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

ground floor entrance hall, metal circular pillar, leveling mortar, concrete shoe, echachado of stone mm, lower arm, separators, cleaning concrete, support plate, overflow, anchor bolts, anchor support plate, anchor bolts with nut locknut to level heights inclinations, welding, leveling mortar, concrete shoe, lower arm, separators, cleaning concrete, support plate, overflow, anchor bolts, anchor support plate, anchor bolts with nut locknut to level heights inclinations, welding, heb pillar, echachado of stone mm, finished tiling, overcrowded, delivery screen, concrete screed, waterproofing lamina oxiasfaltica, forged sanitary cavities, deliveries foundation pillar start heb jointed connection, deliveries foundation circular pillar start articulated joint, flat:, date:, scale:, foundation, esc., detail, constructive detail

Raw text data extracted from CAD file:

PLANTA BAJA RECIBIDOR \W4.00000; h=1m PILAR CIRCULAR METALICO MORTERO DE NIVELACIÓN ZAPATA DE HORMIGÓN "IN SITU" ECHACHADO DE PIEDRA 40 - 80 MM ARMADO INFERIOR SEPARADORES HORMIGÓN DE LIMPIEZA PLACA DE APOYO REBOSADERO PERNOS DE ANCLAJE PLACA DE APOYO Y DE ANCLAJE PERNOS DE ANCLAJE con tuerca y contratuerca para nivelar alturas e inclinaciones SOLDADURA MORTERO DE NIVELACIÓN ZAPATA DE HORMIGÓN "IN SITU" ARMADO INFERIOR SEPARADORES HORMIGÓN DE LIMPIEZA PLACA DE APOYO REBOSADERO PERNOS DE ANCLAJE \W5.70746; PLACA DE APOYO Y DE \W5.70746; ANCLAJE PERNOS DE ANCLAJE con tuerca y contratuerca para nivelar alturas e inclinaciones SOLDADURA PILAR HEB ECHACHADO DE PIEDRA 40 - 80 MM ACABDO DE BALDOSA RECRECIDO MALLAZO DE REPARTO SOLERA DE HORMIGÓN IMPERMEABILIZACIÓN - LAMINA OXIASFALTICA FORJADO SANITARIO - CAVITIES ENTREGAS A CIMENTACIÓN - ARRANQUE DE PILAR HEB UNIÓN ARTICULADA F1 A F10 ENTREGAS A CIMENTACIÓN - ARRANQUE DE PILAR CIRCULAR UNIÓN ARTICULADA F11 A F16 PLANO: PLANO: FECHA: ESCALA: CIMENTACIÓN MARZO-2010 ESC. 1/100 DETALLE 5 DETALLE 6 DETALLE CONSTRUCTIVO

Language	Spanish
Drawing Type	Block
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features
Tags	autocad, base, block, circular, DWG, FOUNDATION, foundations, fundament, heb, pilar, start, union
