Pool Sction DWG Detail for AutoCAD

Pool Sction DWG Detail for AutoCAD

Concrete – Details with technical specifications

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

swimming pool concrete section, cement for a greater, waterproofing of the vessel., the vibration will be performed in a, that there is no segregation, by raising the fine arid., load ratio, the concrete used will have a fire, of relation water, maximum dosage, coefficient of major. of the concrete, coefficient of major. of steel, stuck up, mesh, asphalt screen, sloping, ceramics gresite, gate key, concrete, pool, flange valve, stuck up, brick, section, concrete, brick, concrete cap, siphon casing, bottom sink, concrete, sloping, Cutting key

Raw text data extracted from CAD file:

d 8/20 cm d 8/15 cm d 10/20 cm 20 55 15 15 2 d 12 45 SECCION PISCINA HORMIGON ARMADO cemento baja para una mayor impermeabilizacion del vaso. El vibrado se realizara de forma que no se produzca segregacion por subida del arido fino. Coeficiente de mayoracion carga 1,6 El hormigon utilizado tendra un arido 300 kg/cm2 de P-350 y relacion agua maximo de 20 mm, con dosificacion Coeficiente de mayor. del hormigon 1,5 Coeficiente de mayor. del acero 1,15 Enfoscado Mallazo Tela asfaltica Encachado Ceramica Gresite LLAVE DE COMPUERTA HORMIGON A PISCINA VALVULA 2 BRIDAS ENFOSCADO 1/2 LADRILLO M Seccion L50/50/5 500 100 150 600 100 HORMIGON 1/2 LADRILLO M L50/50/5 TAPA DE HORMIGON ARQUETA SIFONICA P 100 50 SUMIDERO DE FONDO HORMIGON ENCACHADO A LLAVE DE CORTE 20

Language	Spanish
Drawing Type	Detail
Category	Pools & Swimming Pools
Additional Screenshots
File Type	dwg
Materials	Concrete, Steel
