Detail cutting bar and kitchenete

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Painted latex painted washable, Floor matte enamel matt medium transit, Laundry mixer bar monocomando to the line minimalist collection chrome square collection, Built-in washbasin beta tramontina finished pre-polished a pool with drainer, Granite board salt finished, Concrete pit, Granite board, Stainless steel base unit with stainless steel handles, Kitchenet, Stainless steel tube, Kitchenet, N.p.t., Kitchenet

Raw text data extracted from CAD file:

\W1.75755; TARRAJEADO Y PINTADO \W9.78170; LÁTEX LAVABLE PISO PORCELANATO ESMALTADO MATE TRÁNSITO MEDIO 0.60x0.60m. \W4.98479; MEZCLADORA DE LAVADERO BAR \W3.66014; MONOCOMANDO AL MUEBLE LÍNEA \W4.26048; MINIMALISTA COLECCIÓN SQUARE \W9.39891; CROMO \W1.44632; LAVADERO DE EMPOTRAR BETA 40R - \W1.44632; TRAMONTINA ACABADO PREPULIDO \W1.44632; UNA POZA CON ESCURRIDOR \W8.68041; TABLERO DE GRANITO \W8.08763; SAL Y PIMIENTA(DECORSTONE O SIMILAR), \W8.08763; ACABADO PULIDO, e= 2cm \W9.21882; \W7.34800; POYO DE CONCRETO \W9.42207; h= 0.10m TABLERO DE GRANITO PULIDO, e= 2cm MUEBLE BAJO DE MELANIMA e= 18mm con tiradores de acero inoxidable \A1;1.05 \A1;2.90 \A1;.60 \A1;1.45 \A1;.80 \A1;R.30 \A1;.07 \A1;.98 KITCHENET 5 5 TUBO DE ACERO INOXIDABLE ø3 1/2" KITCHENET N.P.T. +13.60 N.P.T. +13.60 KITCHENET \fArial|b0|i0|c0|p34;\H0.8x;PLANTA KITCHENET \fArial|b0|i0|c0|p34;\H0.8x;CORTE 5 5 5 5 5 5

Language	Spanish
Drawing Type	Detail
Category	Bathroom, Plumbing & Pipe Fittings
