Sprocket 48 Teeth 3D DWG Model for AutoCAD
Sprocket 48 teeth; Outside Diameter = 500.67; Dia = 483.53; diameter and depth = 466.39; 31.75 mm step. For a chain with rollers d 19.05 mm diameter and 31.75 mm pitch .
Language | N/A |
Drawing Type | Model |
Category | Industrial |
Additional Screenshots |
![]() |
File Type | dwg |
Materials | |
Measurement Units | |
Footprint Area | |
Building Features | |
Tags | autocad, chain, depth, diameter, DWG, gear, le tuyau, mm, model, parafusos, pipe, robinet, rohr, rollers, schraub, screw, step, teeth, tubos, valve, válvulas, ventil, vis |
