Stainless Steel Profiles Window DWG Block for AutoCAD

Window with stainless steel profiles – Central panel fixed and two folding leaves

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

vertical section, horizontal detail, vescom facing, elevation, horizontal section, swing leaf, horizontal, fixed cloth, ceramic coping, vertical detail

Raw text data extracted from CAD file:

\A1;250.0 \A1;80.0 \A1;80.0 \A1;80.0 \A1;186.0 \A1;68.5 \A1;68.5 \A1;60.0 20.10 ESCALA 1/25 SECCION VERTICAL DETALLE HORIZONTAL ESCALA 1/5 40.40 60.30 40.40 20.10 PARAMENTO EN VESCOM 40.40 60.30 PARAMENTO EN VESCOM 20.10 40.20 80.30 40.20 40.20 PARAMENTO EN VESCOM 40.40 60.30 40.40 20.10 40.40 20.10 40.20 20.10 40.20 40.20 80.30 40.40 60.30 40.40 20.10 ALZADO ESCALA 1/25 SECCION HORIZONTAL ESCALA 1/25 VENTANAL 1 HOJA BATIENTE HORIZONTAL HORIZONTAL HOJA BATIENTE PAÑO FIJO 250.0 80.0 80.0 80.0 186.0 68.5 68.5 60.0 ALBARDILLA CERAMICA DETALLE VERTICAL ESCALA 1/5 VENTANAL 1

Language	Spanish
Drawing Type	Block
Category	Doors & Windows
Additional Screenshots
File Type	dwg
Materials	Steel, Other
Measurement Units	Metric
Footprint Area
Building Features
Tags	autocad, block, central, DWG, fixed, folding, leaves, panel, profiles, stainless, steel, window
