Steel Frame DWG Block for AutoCAD

Steel Frame DWG Block for AutoCAD

Sistema constructivo steel

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

cataloging materials, red ceramic, irons, mortars, concrete, woods, zinc sheet alum, glass wool, eps, plastics, plasters, asphalts, land, others, insulation, enclosures, structure, cataloging functions, references, sidewalk, modena with dvh, modena simple glass, cincalum bwg sheet, profile galley wood, thermal insulation glass wool, Tyveck, phenolic multilaminate, plaster and acrylate fiber, pgc profile, stiffeners pgc profile ep, pgu profile, soil separator filmolietileno, carpet, under carpet, double multilaminate phenolic, plasterboard for wall esp mm, gypsum board for ceiling esp mm, omega mm profile, pgc profile, pgu profile, anchorage on, with cementitious adhesive, lightweight subfloor, platea de hºaº, mci waterproof folder, preboard type superboard, insulation thermal eps walls mezzanine, polyethylene film microns wall, compacted natural terrain, ceiling fan, smoothing, carpentry modena aluminum with grate, slope superboard slope, counter frame, reinforcement plate armor, minimum armor minimum double mesh, inf, coating film, by oxidation, inf. iron to have film without film min., compacted natural terrain, filmolethylene, variant of reinforcement of silver exercise do without, steel frame, whole inclined pgu profile, horizontal pgu profile cut for union, pgu stiffener profile joins both, sidewalk, steel frame, covered photo, logo, esp tec, mezzanine photo, logo, esp tec, photo carpentry, logo, esp tec, photo foundation, logo, esp tec

Raw text data extracted from CAD file:

01 CATALOGACION x MATERIALES CERAMICA ROJA HIERROS MORTEROS HORMIGONES MADERAS CHAPAS ZINC / ALUM LANA de VIDRIO EPS PLASTICOS YESOS ASFALTOS TIERRAS OTROS AISLACIONES CERRAMIENTOS ESTRUCTURA CATALOGACION x FUNCIONES REFERENCIAS 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 25 VEREDA 34 28 32 16 04 11 06 05 24 24 25 27 26 23 15 12 10 09 A B C D E 14 15 33 MODENA CON DVH MODENA VIDRIO SIMPLE 31 31 14 15 15 11 10 19 18 20 15 22 21 13 07 30 08 17 15 13 07 30 08 15 14 14 12 05 04 12 05 01 02 03 01 02 03 04 05 06 07 09 12 13 15 16 18 20 19 CHAPA CINCALUM BWG Nº25 (no se usa+galvanizada PERFIL GALERA 37X0.89 o MADERA 2"x2" AISLANTE TERMICO LANA DE VIDRIO 2" TYVECK MULTILAMINADO FENOLICO 10MM REVOQUE ACRILICOy MALLA FIBRA de VIDRIO(EIFS) PERFIL PGC 100 RIGIDIZADORES PERFIL PGC 100 M/T 200 EP PERFIL PGU 100 SEPARADOR DE SUELO FILMOLIETILENO 200mic ALFOMBRA 10MM BAJO ALFOMBRA 2MM DOBLE MULTILAMINADO FENOLICO 15MM PLACA DE YESO PARA PARED esp 12,5 mm PLACA DE YESO PARA CIELORRASO esp 9 mm PERFIL OMEGA 12.5 MM PERFIL PGC 200 PERFIL PGU 200 ANCLAJE sobre ZOCALO DE H° 8x13cm +Ø 8mm SOLADO+ZOCALO CON ADHESIVO CEMENTICIO CONTRAPISO LIVIANO 5CM ALISADO HIDROFUGO 26 24 23 22 21 08 PLATEA DE HºAº S/CALCULO CARPETA HIDROFUGA MCI 1:3 28 27 CENEFA PREMOLDEADA TIPO SUPERBOARD 14 AISLANTE TERMICO EPS 4mm muros /25mm entrepisos 10 11 FILM DE POLIETILENO 200 MICRONES MURO 29 TERRENO NATURAL ENTOSCADO COMPACTADO 30 BUÑA CIELORRASO CONTRAPISO ALISADO C/PTE H°EPS 1:6 ALISADO 25 31 CARPINTERIA MODENA ALUMINIO CON REJA 33 ANTEPECHO SUPERBOARD CON PENDIENTE A) PREMARCO; B) MARCO; C) HOJA; D) VIDRIO; E) CONTRAMARCO 34 REFUERZO PLATEA H° + ARMADURA Ø8 \A1;H° MINIMO 15 CM, ARMADURA MINIMO DOBLE MALLA Q335 \A0;Ø 8 \S15/15; \A1;MINIMO INF 3cm \A1;CON FILM RECUBRIMIENTO por oxidacion aclarar) \A1;RECUBRIMIENTO INF. HIERRO 3cm AL HABER FILM SIN FILM MIN. 5cm 32 TERRENO NATURAL ENTOSCADO COMPACTADO 17 FILMOLIETILENO 200mic variante de refuerzo de H°A°en platea p ejercicio hacer sin el STEEL FRAME PERFIL PGU 100 inclinado entero PERFIL PGU 100 horizontal cortado para union PERFIL PGU 100 rigidizador une ambos 16 23 28 12 35 34 15 VEREDA 13 12 22 21 11 15 15 15 13 15 15 12 STEEL FRAME FOTO CUBIERTA LOGO esp tec FOTO ENTREPISO LOGO esp tec FOTO CARPINTERIA LOGO esp tec FOTO FUNDACION LOGO esp tec

Language	Spanish
Drawing Type	Block
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Aluminum, Concrete, Glass, Plastic, Steel, Wood, Other
Measurement Units
Footprint Area
Building Features	Car Parking Lot
Tags	adobe, autocad, bausystem, block, construction system, covintec, DWG, earth lightened, erde beleuchtet, frame, losacero, plywood, sistema, sperrholz, stahlrahmen, steel, steel frame, steel framing, système de construction, terre s
