SubmuraciÓN Masonry DWG Detail for AutoCAD

Construction detail of a submuración made in masonry slab uplift.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

existing shoe, wooden plinth, thick plaster lime, white plaster fine plaster, mci insulating layer hidrafugo, Ceramic block for mezzanine ceilings, lightweight expanded clay, regularizing folder mca cm, bulldozer, carpet, compression layer hº e: cm hc, Expanded polystyrene expansion joint cm, wood socket, mci vertical insulator layer, seat mortar, asphalt felt, buña en cielorraso de cm, emphasize hº, slab of underpressure hº aº with inverted armor irons, regularizer mca, bulldozer mass mm, vinyl similar wood, hhrp underfloor, elastic membrane, insulating layer mci waterproof, e.d.p., prestressed joist cm, electrowelded mesh cm, filling common brick in tambourine, white plaster fine plaster, hot shoe hºc, existing shoe demolished hc cm, expansion meeting, contact adhesive, expanded polystyrene expansion joints, thick plaster lime, e.d.p., ext., int., polyethylene film microns, contact adhesive, Mario., I move away. bruno, arq. roxana natalino, students: Gabriel. Paul., cat. arq. h. nottoli, buildings, t. p., group, teacher:, esc .:, Detail of submuration masonry with underpressure slab

Raw text data extracted from CAD file:

Zapata existente Zócalo de madera Revoque grueso a la cal Revoque fino de yeso blanco Capa aisladora (rigida) MCI 1:3 + 105 hidrafugo Bloque ceramico para techos y entrepiso 42x13x25cm \A1;Contrapiso liviano 1:8 arcilla expandida 6cm Carpeta regularizadora MCA 1:1/2:3 2 cm Masa niveladora Alfombra Capa de compresión Hº e: 5 cm HC 1:3:3 Junta de dilatación de poliestireno expandido 2 cm Zócalo madera Capa aisladora vertical MCI 1:3 e=1cm Mortero de asiento 1:3:3 Fieltro asfáltico e=1cm Buña en cielorraso de 2 x 1 cm Recalce de Hº L 1:8 Losa de subpresion Hº Aº 1:3:3 14cm con armadura invertida hierros 10 \A1;Carpeta regularizadora MCA 1:1/2:3 2cm Masa niveladora 3 mm Solado vinilico simil madera Contrapiso HHRP 1:1/4:4:8 18cm Membrana elástica flexible(elastomérica: neopreno) Capa aisladora horizontal (rigida) MCI 1:3 + 10% hidrofugo 2cm E.D.P. Vigueta pretensada 13x9 cm Malla electrosoldada 15x15 cm Relleno ladrillo comun en panderete Revoque fino de yeso blanco Zapata corrida HºC 1:3:3 Zapata existente demolida HC 1:3:3 60x30 cm Junta de expansión 2cm Adhesivo de contacto Juntas de dilatacion poliestileno expandido Revoque grueso a la cal E.D.P. EXT. INT. Film Polietileno 200 micrones Adhesivo de contacto Pujalka, Mario. Guillen, Alejo. Stauber, Bruno. \W3.20000; Arq. Roxana Natalino 05 04 ALUMNOS: Roque, Gabriel. Villalba, Pablo. \W3.20000; CAT. ARQ. H. NOTTOLI CONSTRUCCIONES I T. P. Nº1 Grupo Docente: 2009 ESC.: 1:5 DETALLE DE SUBMURACION MAMPOSTERIA CON LOSA DE SUBPRESION

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Masonry, Wood
Measurement Units
Footprint Area
Building Features
Tags	autocad, base, basement, construction, DETAIL, DWG, FOUNDATION, foundations, fundament, masonry, slab, submuracion
