Tees red. on the run and equal on the branch B1; Sizes- ½” x ½” x ⅜” – 2″ x 2″ x 1½”; 3 views
ADVERTISEMENT
ADVERTISEMENT
Parametric dynamic block whith 3 views. Dimensions in accordance whith EN10242. AutoCad version 2016.
| Language | English |
| Drawing Type | Block |
| Category | Bathroom, Plumbing & Pipe Fittings |
| Additional Screenshots | |
| File Type | dwg |
| Materials | |
| Measurement Units | Metric |
| Footprint Area | |
| Building Features | |
| Tags |
