Wardrobe Detail DWG Detail for AutoCAD

Wardrobe Detail DWG Detail for AutoCAD

Wardrobe – PLANT – VISTA – CORTE

Drawing labels, details, and other text information extracted from the CAD file:

wood., oil based paint or laquer. color depends on spice concept., door handle. oil based paint or laquer. color depends on spice concept. central part in porcelain, enameled., top shelve. blockboard. finished wood veneer, polished, matte., drawer. same as above., open space for shoes., space for safety box. provide electrical point., confirm dimensions of security box, door on solid wood. optional on plywood, veneer same as per wood specifcations., confirm support of this shekve with manufacturer. safety box is heavy.

Raw text data extracted from CAD file:

2,100.0 100.0 2,000.0 394.0 260.0 320.0 434.0 150.0 219.0 434.0 150.0 306.0 916.0 1,514.0 950.0 640.0 460.0 300.0 20.0 394.0 694.0 694.0 1,460.0 780.0 310.0 470.0 203.0 203.0 434.0 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 Wood. Oil based paint or laquer. Color depends on spice concept. Door Handle. Oil based paint or laquer. Color depends on spice concept. Central part in porcelain, enameled. Top Shelve. Blockboard. Finished Wood Veneer, polished, matte. Drawer. Interior base of drawer upholstered in "Poly-Leather" (Plastic Leather) Drawer. Same as above. Open space for shoes. Space for safety box. Provide electrical point. Bar in brass (matte) for hanging clothes. \A1;COTTAGES LF + (Insert Code) Wardrobe \fArial|b1|i0|c0|p34;Front Elevation \A1;COTTAGES LF + (Insert Code) Wardrobe \fArial|b1|i0|c0|p34;Section Confirm Dimensions of Security Box \A1;COTTAGES LF + (Insert Code) Wardrobe \fArial|b1|i0|c0|p34;Side Elevation Door on solid Wood. Optional on Plywood, Veneer same as per wood specifcations. Door on solid Wood. Optional on Plywood, Veneer same as per wood specifcations. Confirm support of this shekve with manufacturer. Safety box is heavy. Door finish. Option A_Door upholstered with textile (easy to clean) and graphic design with local patchwork technique or similar. Option B_Door completely in solid Wood. Provide rubber Shoe. No thicker than 5-10mm (max)

Language	English
Drawing Type	Detail
Category	Furniture & Appliances
Additional Screenshots
File Type	dwg
Materials	Plastic, Wood, Other
Measurement Units	Metric
Footprint Area
Building Features
Tags	autocad, bed, bedroom, closet, corte, DETAIL, DWG, furniture, hanger, plant, vista, WARDROBE
