Detalle constructivo de instalacion de ventana · Constructive detail of window installation

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

support mortar, arabesque tile, ventilation, velux is a registered trademark, velux ggl window installation, side channel edw flashing, asphalt cloth, red line, anchoring brackets, anchor pre-frame, and edw flashing with asphalt fabric placed after the, installation of the window, upper gutter, top, window velux model ggl, flashing edw, bib, plaster, edw flashing, tile, edw, ggl, arabe

Raw text data extracted from CAD file:

30-60mm MAX. 130 30-60mm 60-150mm \A1;MAX. 130 \A1;60-150mm \A1;30-60mm \A1;30-60mm Fibrocemento/Onduline Mortero de apoyo Teja arabe / / / / Ventilacion / Teja arabe MAX. 130 60-150mm / R VELUX es una marca registrada C 1994 VELUX GROUP 3VO.217.3.37/180194 Instalacion de ventana VELUX GGL Fibrocemento/Onduline bajo teja arabe. Tapajuntas EDW canal lateral 30-60mm Tela asfaltica / 30-60mm Linea roja Escuadras de anclaje Premarco de anclaje / y tapajuntas EDW con / Seccion B-B 1:5 / Tela asfaltica colocada despues de la / Mortero de apoyo instalacion de la ventana canalon superior Remate Ventana VELUX modelo GGL Tapajuntas EDW, babero Tela asfaltica / Enlucido Tela asfaltica / / Fibrocemento/Onduline Seccion A-A 1:5 Teja arabe Tapajuntas EDW, 03 10. 02.94 Teja EDW GGL 1:20 A A B B arabe

Language	Spanish
Drawing Type	Detail
Category	Doors & Windows
