Windows Tubular Carpentry DWG Plan for AutoCAD

Windows tubular carpentry – Details in elevation and plant

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

tubular window, elevation, cut and-and, trolley, x-x cut, z-z cut, silicon, notes: the tubular profiles will have a final finish of paint comex brand black metallic, applied with a two-hand gun at least. all joints will be welded and ground to eliminate edges in the joints., notes: the tubular profiles will have a final finish of paint comex color metallic navy blue, applied with a gun at least two hands. All joints will be welded and ground to eliminate edges in the joints.

Raw text data extracted from CAD file:

1.50 0.48 0.51 0.48 0.02 0.02 0.39 0.68 0.44 0.68 0.45 0.80 0.30 0.50 1.06 1.07 C-2 C-1 C-3 C-5 C-4 C-6 C-7 C-8 C-9 CORTE No. 6 CORTE No. 7 CORTE No. 8 CORTE No. 9 ZV-121 ZV-106 ZV-103 ZV-106 ZV-106 ZV-106 ZV-103 ZV-121 Cristal de 6mm Cristal de 6mm Cristal de 6mm Cristal de 6mm Canaleta ZV-154 Tornillo 3/4" Tornillo 3/4" Tornillo 3/4" Tornillo 3/4" Canaleta ZV-154 Canaleta ZV-154 VENTANA TUBULAR VENTANA TUBULAR Canaleta ZV-154 CORTE No. 2 CORTE No. 1 CORTE No. 3 CORTE No. 4 CORTE No. 5 Canaleta ZV-154 Tornillo 3/4" Cristal de 6mm Cristal de 6mm Tornillo 3/4" Canaleta ZV-154 Cristal de 6mm Tornillo 3/4" Cristal de 6mm Canaleta ZV-154 Tornillo 3/4" Tornillo 3/4" Cristal de 6mm Canaleta ZV-154 ZV-121 ZV-103 ZV-121 ZV-121 ZV-106 ZV-106 ZV-121 ALZADO 5 5 5 5 5 5 5 5 5 5 5 5 5 5 VENTANA TUBULAR ALZADO Y Y X X Z Z ZV-121 ZV-121 ZV-101 ZV-122 ZV-101 ZV-103 ZV-124 ZV-121 ZV-121 ZV-122 ZV-123 ZV-122 ZV-121 ZV-121 ZV-101 ZV-124 VENTANA TUBULAR CORTE Y-Y CARRO CORTE X-X CORTE Z-Z 5 5 Cristal de 3mm Silicon CanaletaZV-154 Tornillo 3/4" CanaletaZV-154 Tornillo 3/4" Silicon Cristal de 3mm NOTAS: LOS PERFILES TUBULARES TENDRAN UN ACABADO FINAL DE PINTURA MARCA COMEX COLOR NEGRO METALICO, APLICADO CON PISTOLA A DOS MANOS COMO MINIMO. TODAS LAS UNIONES SERAN SOLDADAS Y ESMERILADAS PARA ELIMINAR BORDES EN LAS UNIONES. NOTAS: LOS PERFILES TUBULARES TENDRAN UN ACABADO FINAL DE PINTURA MARCA COMEX COLOR AZUL MARINO METALICO, APLICADO CON PISTOLA A DOS MANOS COMO MINIMO. TODAS LAS UNIONES SERAN SOLDADAS Y ESMERILADAS PARA ELIMINAR BORDES EN LAS UNIONES.

Language	Spanish
Drawing Type	Plan
Category	Doors & Windows
Additional Screenshots
File Type	dwg
Materials	Other
Measurement Units	Metric
Footprint Area
Building Features
Tags	autocad, carpentry, details, DWG, elevation, plan, plant, tubular, window, windows
