Wire Netting Details DWG Detail for AutoCAD

Wire Netting Details DWG Detail for AutoCAD

Wire Netting Details

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

– the doors are equipped with a universal key lock system, tension post, foundations are considered minimum, – the dimensions indicated in the galvanized wire mesh of simple torsion, note: tension wires

Raw text data extracted from CAD file:

PERFIL ACERO GALVANIZADO 40x40mm PERFIL ACERO GALVANIZADO 80x80mm 1.50 \A1;3.00 - LAS PUERTAS IRAN DOTADAS DE UN SISTEMA DE CERRADURA CON LLAVE UNIVERSAL 1.50 \A1;0.05 \A1;0.30 \A1;0.40 \A1;2.05 1.5mm ESPESOR TUBO d50 EXTERIOR \A1;3.50 POSTE DE TENSION CIMENTACIONES SE CONSIDERAN MINIMAS - EL HORMIGON EN MACIZOS SERA HM-20 - LAS DIMENSIONES INDICADAS EN LAS MALLA METALICA DE ALAMBRE GALVANIZADO DE SIMPLE TORSION NOTA : TUBO d35 mm ARRIOSTRAMIENTOS CADA 35mts \A1;3.50 ALAMBRES DE TENSION

Language	Spanish
Drawing Type	Detail
Category	Doors & Windows
Additional Screenshots
File Type	dwg
Materials	Other
Measurement Units	Metric
Footprint Area
Building Features
Tags	autocad, DETAIL, details, DWG, gate, wire
