Tuerca Hexagonal en 3D con dimensiones ASME B18.2.2, dibujado en mm

Tipo de rosca: BASTA (UNC)
Numero de hilos por pulgada Nh: 8 (1)
Paso (p) = 0.0783 in (2.38 mm)
Diámetro mayor (d) = 1.0000 in (25.40 mm)
Diámetro menor (dr) = 0.8376 in (21.28 mm)

3D Hex Nut with ASME B18.2.2, drawn in mm

Dimensions Thread Type: COARSE (UNC)
Number of threads per inch Nh: 8 (1)
Pitch (p) = 0.0783 in (2.38 mm)
Major diameter (d) = 1.0000 in (25.40 mm)
Minor diameter (dr) = 0.8376 in (21.28 mm)
