3D Model of Industrial Storage Drum with Reinforced Framework

ADVERTISEMENT

ADVERTISEMENT

or

This 3D model depicts a vertical cylindrical industrial storage drum with an integrated reinforcement framework. The structure features a latticed steel support system with multiple horizontal reinforcement rings positioned strategically along the drum’s height. The model shows a detailed structural framework approximately 8500mm tall with a diameter of roughly 7000mm, designed to withstand significant internal pressures and external forces. The drum includes access platforms with safety railings at different elevations for maintenance purposes. The structural grid pattern provides optimal strength-to-weight ratio while maintaining the vessel’s integrity under various loading conditions. Notable engineering considerations include the triangulated base structure for enhanced stability and the reinforced top section, which likely houses inlet/outlet connections. This type of pressure vessel is commonly used in chemical processing, petroleum refining, or water treatment facilities where containment of process fluids is critical.

Language English
Drawing Type Model
Category
Additional Screenshots
File Type dwg
Materials Steel
Measurement Units Metric
Footprint Area 50 - 149 m² (538.2 - 1603.8 ft²)
Building Features
Tags , , , , , ,
or
ADVERTISEMENT

Release Information

  • Price
    :

    $7.50

  • Categories
    :
  • Released
    :

    April 13, 2025
