Detail External Bricks Wall and plaster panels in interior – Roof with softeners

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Meeting wall panel ceiling existing plaster. Elastic base series snbs. Uprights mm. Multi-layer insulation panel. Sonodan plus acoustic sandwich. Multi-layer insulation panel. Sonodan plus continuous roof profile. Laminar gypsum board of mm. Steel shock absorber series sntm snhm. Roof tile panel of rock wool. Density rocdan sandwich acoustic. Laminated plasterboard

Raw text data extracted from CAD file:

ENCUENTRO PARED MEDIANERA - TECHO 1. Soporte existente enlucido. 2. Base elástica SERIE SNBS. 3. Perfil montante 46 mm. 4. Panel multicapa de aislamiento. SONODAN PLUS 5. Sandwich acústico. 6. Panel multicapa de aislamiento. SONODAN PLUS 7. Perfileria techo continuo. 8. Placa de yeso laminar de 13 mm. 9. Amortiguador de acero SERIE SNTM o SNHM. 10. Perfileria techo (Primario - Secundario). 11. Panel de lana de roca. Densidad 70 kg/m 3 . ROCDAN 231/40 12. Sandwich acústico. 2 placas yeso laminar 13 + M.A.D.4

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Steel
