Detail External Bricks Wall and plaster panels in interior – Roof with softeners

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Meeting wall ceiling support existing plaster. Multi-layer insulation panel. Sonodan plus profile uprights mm. Elastic base series snbs. Acoustic sandwich. Gypsum plasterboards m.a.d. Multi-layer insulation panel. Sonodan plus continuous roof profile. Laminar gypsum board of mm. Steel shock absorber series sntm snhm. Roof tile panel of rock wool. Density rocdan sandwich acoustic. Gypsum plasterboards m.a.d.

Raw text data extracted from CAD file:

ENCUENTRO PARED - TECHO 1. Soporte existente enlucido. 2. Panel multicapa de aislamiento. SONODAN PLUS 3. Perfil montante 46 mm. 4. Base elástica SERIE SNBS. 5. Sandwich acústico. 2 placas yeso laminar 13 + M.A.D. 4 6. Panel multicapa de aislamiento. SONODAN PLUS 7. Perfileria techo continuo. 8. Placa de yeso laminar de 15 mm. 9. Amortiguador de acero SERIE SNTM o SNHM. 10. Perfileria techo (Primario - Secundario). 11. Panel de lana de roca. Densidad 70 kg/m 3 . ROCDAN 231/40 12. Sandwich acústico. 2 placas yeso laminar 13 + M.A.D. 4
