Ailsante Continuous Enclosure On A Steel Frame DWG Full Project for AutoCAD
Construction detail of own elaboration for the project of a perfume factory. It is a continuous thermal envelope on deck and facade insulation; which gives better thermal insulation and water properties. The enclosure is placed on a structure of steel columns and beams void; together with a deck substructure corrugated panels with embedded thermal insulation supported on steel joists
Drawing labels, details, and other text information extracted from the CAD file:
boyd steel beam. false ceiling. gypsum cardborad. t. acoustic isolation of rock wool. t. aluminum subestructure. mullium and transom of acoustic isolation of rock wool. aluminium substructure. plaster cardborad. t. corrugated aluminium sheet. t: metal profile. steel straps. sheet steel reinforced concrete decking. thermal insulation of extruded rigid polystyrene. waterproofing sheet. epdm. reinforced mortar external finishing. t.
Raw text data extracted from CAD file:
| Language | English |
| Drawing Type | Full Project |
| Category | Construction Details & Systems |
| Additional Screenshots |
 |
| File Type | dwg |
| Materials | Aluminum, Concrete, Steel |
| Measurement Units | |
| Footprint Area | |
| Building Features | Deck / Patio |
| Tags | autocad, barn, construction, construction details, continuous, cover, dach, deck, DETAIL, DWG, elaboration, enclosure, factory, frame, full, hangar, lagerschuppen, manufactures, plasterboard, Project, roof, shed, steel, structure, terrasse, thermal, toit |
